Rudder Oscillation Due to Yaw Damper Gyro Failure

Casualties unknown • Anchorage, AK, US

A rudder oscillation shook an airplane during gate parking. Investigation found the yaw damper was solely responsible, caused by a loss of grease and bearing damage in the yaw rate gyro.

What happened

While the aircraft was parked at the gate, the rudder began to oscillate rapidly. This movement was vigorous enough to shake the entire airframe. The oscillation occurred without any corresponding movement of the rudder pedals in the cockpit.

The investigation

Post-incident testing determined that the rudder was oscillating approximately 1.5 degrees either side of centerline. The motion was controlled solely by the yaw damper system. Further examination revealed a loss of grease to the yaw rate gyro spin bearings. This lack of lubrication resulted in corresponding damage to both the spin and gimbal bearings.

Findings

The yaw damp coupler and gyro had accumulated 24,850 hours in service before the failure occurred. The mechanical degradation of the gyro bearings led to the uncommanded rudder movement.

Probable cause

Loss of grease to the yaw rate gyro spin bearings, resulting in damage to the spin and gimbal bearings.

All Boeing 737-800 accidents →

Frequently asked questions

What happened in the 1998-03-11 Boeing 737-205 accident near Anchorage, AK?

A rudder oscillation shook an airplane during gate parking. Investigation found the yaw damper was solely responsible, caused by a loss of grease and bearing damage in the yaw rate gyro.

What aircraft was involved and where did it happen?

The accident on 1998-03-11 involved a Boeing 737-205, registration N733AR, operated by Arco Alaska, Inc., at Anchorage, AK.

What was the probable cause of the accident?

Loss of grease to the yaw rate gyro spin bearings, resulting in damage to the spin and gimbal bearings.

Investigation report by the U.S. National Transportation Safety Board (NTSB) historical archive. Original record: https://carol.ntsb.gov/event/20001211X09616. This page is a structured re-presentation; facts and quotes are in the National Transportation Safety Board (NTSB), United States.
